SX-160DA / SX-120DA DUAL WIRE POCKET SPRING MACHINE
With Red Dot : Wire Diamater 2.2MM
Without Red Dot : Wire Diamater 1.8MM
|
Technical Data | |
|
Spring Type |
Barrel or Cylindrical |
|
Capacity |
160/120 Springs per min |
|
Spring Waist ext Dia |
Φ45-Φ70MM ( >Φ70 MM on request ) |
|
Steel Wire Gauge |
Φ1.4-Φ2.3MM( <Φ1.4MM on request) |
|
Pocket Height |
70-220MM(<70 or >220MM on request) |
|
Fabric Width |
≤650MM |
|
Fabric Thickness |
≥60G/M2 |
|
Fabric Diameter |
≤1M |
|
Main Drive Power |
30KVA |
|
Air Consumption |
10M3/H |
|
Weight |
4830KG |
|
Power Requirement |
380V，3 Phase，50-60HZ (Option：415V-480V,，220V) |
